Professional 125Khz EMID/13.56Mhz IC RFID Card Reader for Access Control System, Ultra Slim Metal with Wiegand26/34,RS232,RS485,UART TTL Formats (UART TTL, IC Card&NFC)

Please Note The access control reader cannot store user data, and cannot add user cards, passwords, or fingerprint users. It is just a tool for expanding card swiping or password unlocking, relying on extended reading heads on devices such as access control all-in-one machines, fingerprint attendance machines, and multi door controllers. Product parameters Product name : Metal Access Control Card Reader Operating Frequency : 13.56Mhz Sensing distance : 0-15CM Operating voltage : DC 9V-16V Communication format : Wiegand 26/34, RS485，RS232, TTL level Baud rate : Communication baud rate 9600.N.8.1 Operating temperature : -25℃-85℃ Transmission distance : WG(100 meters), RS232 (10 meters), RS485 (1200 meters) Shell material : Tempered Glass, Aluminum Alloy Card type: EMID card, IC Card Options(does not support HID, Cobra, APCiK, etc.) Size: 86*86*9mm Night Light: Yes Product parameters 1 x RFID Card Reader 1 x User Manual

• ✔️ Card type: Supports 125Khz EMID Cards & 13.56Mhz IC/NFC Options. (does not support HID, Cobra, APCiK, etc.)
• ✔️ Industrial-Grade Connectivity & Protection: Wiegand26/34, RS485, RS232 & UART TTL outputs; 15KV surge protection + anti-miswiring circuit.
• ✔️ Aluminum Alloy: Crafted with durable tempered glass and robust aluminum alloy, this reader withstands harsh environments.
• ✔️ Thin design: The micro-satin metal frame is only 9 mm thick.
• ✔️ Intuitive Visual/Audio Feedback: Green LED + Buzzer indicates valid card; Blue light for standby; Anti-interference.
